"LNG LOADING PIECE

SHORT PIECE 16X16” (STBD)

OD 595.3~597MM

ID 381MM

LENGTH 350MM

FLANGE THINKNESS 37MM

SURFACE FINISH 0.2 RA

JOINTING PACE SERRATION DEPTH 0.05

TOOL NOSE RADIUS 1.6

SERRATION PITCH 0.8

SURFACE FFINISH 3.2/6.3 RA

CONTINUOS SPIRAL R1/6X0/8 PIITH X 0/05MM DEEP " "Assembly: ENGINE CONTROL CONSOLE I [Component No. - Drawing No.l: I???]- [???1

Maker: .

HHI CO., LTD

Model:

FLOOR MOUNTING & SELF-STANDING

" HHI CO. LTD.
