YANMAR Diesel Engine Spare Parts TYPE:6N165-EN

TYPE:YANMAR 6N165-EN

 1 CYLINDER BLOCK

 2 WASHER Part No. 144626-39370

 3 CAP,FILLER Part No. 135655-01950

 4 WASHER Part No. 133614-11890

 5 BOLT, M10X25 Part No. 26206-100252

 6 CYLINDER LINER & HEAD GASKET

 7 GASKET HEAD GASKET T=2.0 Part No. 133688-01393

 8 LINER ASY,CYLINDER Part No. 733614-01851-C

 9 PACKING, LINER RUBBER Part No. 133654-01280

 10 BAND, CYL.LINER RBBR.(S) Part No. 133654-01290

 11 O-RING CYL’LINER Part No. 152623-01300

 12 PACKING T=0.2(SUS) Part No. 133614-01260

 13 PACKING T=0.4(SUS) Part No. 133614-01270

 14 CYLINDER SIDE COVER

 15 PACKING,SIDE COVER Part No. 152623-01414

 16 CYLINDER SIDE COVER

 17 GASKET, CYL. SD. COVER Part No. 133670-01460

 18 GEAR HOUSING

 19 GASKET, LIQUID Part No. 977770-1207F

 20 O-RING, G55 Part No. 24321-000550

 21 GEAR HOUSING COVER

 22 GASKET Part No. 133614-01560

 23 WASHER, 12 Part No. 22117-120000

 24 FLYWHEEL HOUSING Part No.

 25 GASKET Part No. 133614-01350

 26 WASHER, 8 Part No. 22117-080000

 27 CAMSHAFT CHAMBER COVER

 28 GASKET Part No. 133614-01981

 29 MAIN METAL

 30 MAIN BEARING Part No. 133614-02102

 31 THRUST BEARING Part No. 133614-02200

 32 STRAIGHT PIN Part No. 22312-060100

 33 CAMSHAFT BEARING

 34 BUSH, CAMSHAFT Part No. 133670-02400

 35 CYLINDER HEAD & DECOMPRESSION

 36 O-RING P39 Part No. 152633-11750

 37 PACKING Part No. 152623-11860

 38 VALVE ROTATOR Part No. 27320-130450

 39 SEAL, VALVE STEM Part No. 133654-11141

 40 O-RING, 1AP12.0 Part No. 24311-000120

 41 VALVE , EXH(STL) Part No. 152623-11131

 42 WASHER Part No. 540623-53360

 43 NUT, M14 Part No. 26606-140002

 44 SLEEVE, NOZZLE Part No. 152623-11852

 45 COTTER Part No. 27310-120001

 46 GUIDE, SUC.VALVE Part No. 152623-11160

 47 VALVE ,SUCTION（STL） Part No. 152623-11100

 48 GUIDE, EXH.VALVE Part No. 152633-11181

 49 SEAT SUC. VALVE(S) Part No. 152623-11080

 50 SEAT EXH. VALVE(S) Part No. 152623-11090

 51 BONNET & VALVE ROCKER ARM SUPPORT

 52 GASKET, BONNET Part No. 133670-11280

 53 SUCTION BEND

 54 GASKET Part No. 133614-12311

 55 GASKET Part No. 133670-12200

 56 BEND Part No. 133614-12300

 57 BOLT, M10X25 Part No. 26206-100252

 58 BOLT, M10X130 PLATED Part No. 26206-101302

 59 EXHAUST MANIFOLD

 60 BOLT, M12X30 Part No. 26203-120302

 61 GASKET Part No. 133614-13200

 62 IDLE GEAR

 63 LOCK WASHER Part No. 132310-14660

 64 TURBOCHARGER

 65 GASKET, EXH. BEND Part No. 133670-18410

 66 GASKET Part No. 133670-18400

 67 AIR COOLER

 68 PACKING,SIDE PLATE Part No. 133614-18780

 69 PACKING, RETRN HEADER Part No. 133614-18770

 70 PACKING, IN/OT. HEADER Part No. 133614-18760

 71 PACKING, C.W.FLANGE Part No. 132500-49250

 72 ANTICORROSIVE ZING40X40 Part No. 27200-400400

 73 PACKING Part No. 132310-09330

 74 AIR DUCT

 75 O-RING, 4CP112. Part No. 24314-001120

 76 GASKET Part No. 133670-18250

 77 PACKING Part No. 136606-18192

 78 HOSE Part No. 133614-18190

 79 GASKET Part No. 133854-18340

 80 PISTON & CONNECTING ROD

 81 PISTON RING(CYL/SET) Part No. 733670-22500

 82 RING, PISTON Part No. 152623-22100

 83 RING, PISTON Part No. 152623-22141

 84 RING, PISTON Part No. 133670-22130

 85 RING, OIL CONTROL Part No. 152623-22161

 86 CRANKPIN BEARING Part No. 133960-23454

 87 BOLT, ROD Part No. 133614-23200

 88 PLATE Part No. 152623-23270

 89 BOLT M8X15 Part No. 140623-23280

 90 WASHER，BELLEVILLE Part No. 138613-23290

 91 METAL PISTON PIN Part No. 133614-23101

 92 LUB OIL PUMP & SAFETY VALVE

 93 PACKING Part No. 133614-32310

 94 WASHER,TONGUED Part No. 126650-14770

 95 TURBOCHARGER

 96 SHAFT ASSY (RECONDITION PART) Part No. XNU14N10E06

 97 NUT Part No. XNN371506

 98 SEAL RING Part No. XNN361008

 99 SEAL RING Part No. XNU210547

 100 RING Part No. XNU141008

 101 RETAINER Part No. XNH174404

 102 SHIELD, OIL Part No. XNU14N55B00

 103 SNAP RING Part No. XNN366005

 104 BOLT M6 Part No. XNN38N60N11

 105 WASHER (M6 Part No. XJB652016

 106 FLUSH HEAD SCREW M6 Part No. XJA121076

 107 WASHER Part No. 946009-27305

 108 O-RING Part No. XJC825018

 109 FLOATING METAL Part No. XNN36N64N03

 110 BEARING, THRUST Part No. XNU146602

 111 LUB OIL COOLER

 112 O-RING Part No. 24321-001550

 113 ANTICORROSIVE ZING40X40 Part No. 27200-400400

 114 PACKING Part No. 132310-09330

 115 PACKING Part No. 137800-33380

 116 LUB OIL STRAINER

 117 O-RING, 1AP53 Part No. 24311-000530

 118 GASKET Part No. 148616-35130

 119 ELEMENT, LUB OIL（200 MESH） Part No. 152623-35150

 120 O-RING Part No. 148616-35220

 121 O-RING,15.5X3,L.O. Part No. 148616-35570

 122 BOLT, M12X200 HEX Part No. 26206-122002

 123 LUB OIL STRAINER(TURBO)

 124 ELEMENT Part No. 141646-35091

 125 GASKET(NON-ASB) Part No. 145643-35611

 126 LUB OIL THERMOSTAT

 127 SEAL Part No. 123682-48570

 128 O-RING, G65 Part No. 24321-000650

 129 THRERMOSTAT Part No. 133614-38210

 130 PACKING Part No. 43400-002931

 131 LUB OIL SUCTION PIPE

 132 O-RING, 1AG70.0 Part No. 24321-000700

 133 O-RING, 1AG75.0 Part No. 24321-000750

 134 LUB OIL PIPE (PUMP STRAINER)

 135 O-RING Part No. 24321-000550

 136 LUB OIL PUPE (STRAINER-COOLER)

 137 O-RING Part No. 24321-000550

 138 O-RING Part No. 24311-000480

 139 PACKING Part No. 43400-004000

 140 LUB OIL PIPE (THERMOSTAT-ENGINE)

 141 O-RING Part No. 24321-000550

 142 O-RING Part No. 24321-000550

 143 PACKING Part No. 23414-160000

 144 LUB OIL PIPE (FOR TURBO)

 145 GASKET OVAL Part No. 43400-002971

 146 GASKET Part No. 43400-002901

 147 GASKET, 26X1.5 Part No. 23428-260000

 148 PACKING Part No. 23414-160000

 149 PACKING,COPPER Part No. 23414-180000

 150 COOLING FRESH WATER

 151 GASKET Part No. 133614-42120

 152 O-RING, P28 Part No. 24311-000280

 153 SEAL, OIL TC355511 Part No. 24421-355511

 154 BEARING Part No. 24101-063074

 155 BEND WASHER Part No. 141616-42270

 156 PACKING Part No. 132300-42140

 157 SEAL MECHANICAL Part No. 137610-42492

 158 LOCK WASHER Part No. 140623-83910

 159 COLLAR Part No. 141616-42261

 160 BEARING, BALL 6207U Part No. 24102-062074

 161 COOLING FRESH WATER COOLER

 162 PACKING Part No. 140623-48151

 163 THERMOSTAT, 71C Part No. 140623-48250

 164 PACKING(A) Part No. 146613-44400

 165 PACKING(B) Part No. 146613-44410

 166 O-RING, 1AG210 Part No. 24321-002100

 167 PACKING Part No. 137800-33380

 168 ANTICORROSIVE ZING40X40 Part No. 27200-400400

 169 PACKING Part No. 132310-09330

 170 GASKET,C.W Part No. 152623-49331

 171 BOLT, JOINT 6 Part No. 23857-060000

 172 COVER A, SIDE Part No. 133614-44050

 173 COOLING WATER BY-PASS VALUE

 174 PACKING, C.W. FLANGE Part No. 132500-49250

 175 PACKING, 65X1.5 ROUND Part No. 23438-065000

 176 COOLING FRESH WATER PIPE Part No.

 177 GASKET Part No. 43400-003170

 178 PACKING, 50X1.5 ROUND Part No. 23438-050000

 179 O-RING Part No. 24311-000750

 180 COOLING FRESH WATER PIPE(HEADER EXH. MANIFOLD)

 181 GASKET Part No. 43400-002901

 182 PACKING Part No. 133614-49142

 183 COOLING FRESH WATER (EXH. MANIFOLD)

 184 GASKET Part No. 43400-003170

 185 GASKET C.W. Part No. 152623-49331

 186 COOLING SEA WATER PIPE (PUMP-C.W.COOLER)

 187 PACKING Part No. 152694-49320

 188 BOLT Part No. 26206-100302

 189 PIPE, RUBBER Part No. 148816-49710

 190 GASKET, 5K65X1.5 Part No. 23438-065000

 191 C.S.W PIPE (F.W.COOLER-L.O COOLER)

 192 GASKET Part No. 138673-01990

 193 PIPE, RUBBER Part No. 148816-49710

 194 C.S.W PIPE (L.O COOLER-AIR COOLER)

 195 PIPE, RUBBER Part No. 148816-49710

 196 PACKING Part No. 138673-01990

 197 FUEL INJECTION PUMP

 198 O-RING Part No. 24316-000310

 199 O-RING(V) Part No. 133670-51380

 200 VALVE ASSY, DELIVERY Part No. 146603-51300

 201 VALVE ASSY, DELIVERY Part No. 133670-51910

 202 SPRING, DELIVERY Part No. 137600-51332

 203 DEFLECTOR Part No. 133670-51264

 204 O-RING Part No. 24316-000160

 205 PLUNGER ASSY Part No. 133670-51101

 206 PLUNGER ASSY Part No. 133670-51102

 207 O-RING Part No. 137679-51891

 208 FUEL FEED PUMP

 209 OIL SEAL SC20407 Part No. 24411-204007

 210 FUEL FEED PUMP DRIVING DEVICE Part No.

 211 BEARING, BALL Part No. 24101-060074

 212 BEARING, BALL 6207U Part No. 24101-062074

 213 FUEL INJECTION VALVE

 214 O-RING Part No. 24311-000400

 215 O-RING Part No. 152623-53360

 216 COPPER PACKING Part No. 23414-120000

 217 COPPER PACKING Part No. 133670-11930

 218 NOZZLE DL150T386(LOCK) Part No. 152623-53500

 219 NOZZLE DL150T386(HOLE) Part No. 152623-53500

 220 FUEL STRAINER

 221 PACKING Part No. 137600-55930

 222 PACKING Part No. 137600-55910

 223 O-RING Part No. 24321-000250

 224 PACKING Part No. XP2618210NA

 225 PACKING A23 Part No. 138613-35300

 226 GASKET, 23X1.5 Part No. 23428-230000

 224 FUEL PIPE (FEED PUMP-MAIN PIPE)

 225 SEAL WASHER 16 Part No. 153672-59980

 226 O-RING Part No. 24321-000300

 227 GASKET, 5K15X1.5 Part No. 23438-015000

 228 GASKET, 26X1.5 Part No. 23428-260000

 229 FUEL MAIN PIPE & FUEL INJECTION PIPE

 230 PACKING Part No. 152623-59421

 231 PACKING(B) Part No. 152623-59450

 232 SEAL WASHER 20 Part No. 153672-59970

 233 FUEL RETURN PIPE

 234 SEAL WASHER 12S Part No. 153672-59920

 235 FUEL INJECTION PIPE

 236 SEAL WASHER Part No. 22190-080006

 237 SEAL WASHER 12S Part No. 153672-59920

 238 FUEL OVERFLOW PIPE

 239 PACKING COPPER Part No. 23414-060000

 240 HYDRAULIC OIL GOVERNOR DRIVING DEVICE

 241 SEAL, OIL Part No. 158510-61030

 242 PACKING Part No. 158510-61061

 243 GASKET Part No. 158510-61071

 244 BEARING, KT182412 Part No. 24162-182412

 245 SEAL, OIL Part No. 158510-61380

 246 O-RING Part No. 158510-61591

 247 BEARING ASSY Part No. 758510-61180

 248 GUAGE Part No. 158510-61490

 249 PIN Part No. 158510-61340

 250 O-RING, 1AS100.0 Part No. 24341-001000

 251 HYDRAULIC OIL GOVERNOR DRIVING DEVICE

 252 GASKET Part No. 43400-004020

 253 BEARING, BALL 6005NTN Part No. 24101-060054

 254 WASHER, 14 POLISHED Part No. 22137-140000

 255 PIN, COTTER 3.2X32 Part No. 22417-320320

 256 SPEED CONTROL DEVICE

 257 PIN, SNAP6 Part No. 22372-060000

 258 START/STOP HANDLE& LINE Part No.

 259 PIN, COTTER Part No. 22417-200200

 260 GEBERATOR DEVICE DRIVING

 261 SEAL, OIL TC254008 Part No. 24421-254008

 262 BEARING, BALL 6205 Part No. 24101-062054

 263 GENERATOR

 264 V-BELT, A 36H Part No. 25112-003601

 265 BOLT Part No. 45521-009171

 266 PLATE Part No. 152623-23270

 267 RELAY Part No. 46111-013840

 268 INPUT SHAFT

 269 INSULATOR Part No. 137690-21540

 270 INSULATOR Part No. 137690-21540-A

 271 LUB OIL COOLER

 272 O-RING, 1AP90.0 Part No. 24311-000900

 273 O-RING, 1AS36.0 Part No. 24341-000360

 274 ZINC, SCREW 20X37 Part No. 27210-200370

 275 PACKING Part No. 123210-09310

 276 PACKING COPPER Part No. 23414-250000
