Cummins Diesel Engine Spare Parts TYPE: 6135ACaf

TYPE:6135ACaf

 BORE 135; STROKE 150; CONTINUOUS POWER 94kW

 Serial No. :11952

 Fig. I-1a,I-1b CYLINDER BLOCK (1)

 1 Cylinder liner Part No. 761W-020-002b

 2 Seal ring cylinder liner Part No. 761-02-003a

 3 Stud, cylinder head Part No. 761W-020-004b

 4 Nut, cylinder head Part No. 761W-020-005a

 Fig. I-3 OIL SUMP (1)

 5 Oil sump (sheet metal) Part No. A761-03-010

 Fig. I-7 CYLINDER HEAD

 6 Exhaust valve Part No. 761-04-041a

 7 Intake valve Part No. 761-04-042a

 8 Valve seat insert, exhaust Part No. A761-04-005

 9 Gasket, intake manifold Part No. A761-04-014

 10 Gasket, exhaust manifold Part No. A761-04-015a

 11 Joint screw Part No. M8x1x20/512-1

 12 Copper washer Part No. 8×14/386-1

 13 Nut Part No. BM8GB51-66

 14 Nut Part No. BM10GB51-66

 15 Spring washer Part No. 10GB93-66

 Fig. I-10 GEAR TRAIN (1)

 16 Idle gear Part No. 761-07-003a

 17 Spacer Part No. 761-07-009a

 18 Lock washer Part No. 60GB858-67

 19 Main timing gear Part No. 761-07-002a

 20 Woodruff key Part No. 6×28 GB1099-72

 21 Drive shaft, injection pump Part No. A761-07-002

 22 Woodruff key Part No. 5×19 GB 1099-72

 23 Coupling drive Part No. 761-07-025b

 24 Coupling jaw Part No. 761-07-026c

 Fig I-16 INTAKE MANIFOLD, EXHAST MANIFOLD AND AIR CLEANER(1)

 25 Air cleaner element (paper type) Part No. K2410

 Fig I-20LUBRICATING OIL PUMP (1)

 26 Oil pump assy Part No. 761-15-000a

 27 Gasket Part No. 761-15-001a

 Fig I-25LUBRICATING OIL COOLER (WATER-COOLED TYPE) (1)

 28 Oil cooler assy Part No. 761G-18d-000

 Fig 1-27 LUBE OIL PIPINGS (1)

 29 Gasket Part No. 761G-19-070

 30 Hose assy.,engine to oil cooler Part No. 761G-19-007c

 31 Hose assy., oil cooler to filter Part No. 761G-19-007c

 Fig 1-34 FUEL PIPINGS (1)

 32 Fuel hose assy., injection pump inlet Part No. A761-26-014

 33 Fuel hose assy., feed pump to filter Part No. 761G-26-054a

 34 Fuel hose assy., return flow Part No. 763G-26-002a

 Fig 1-36 INJECTOR

 35 Nozzle couple Part No. 3127-10

 Fig. I-39 COVERNOR for type BINJECTION PUMP

 36 Fuel injection type BH6B100YS29Y & covernor type TQ250/750 B50A ASSEMBLY

 Fig 1-46 INSTRUMENT SYSTEM

 37 Temperaturegauge,water Part No. 2000/911-1

 38 Pressuregauge,lubeoil Part No. 761-31-003d

 39 Temperaturegauge,lubeoil Part No. 2000/911-2
