MAN B&W DIESEL ENGINE SPARE PARTS TYPE:6L42MC

TYPE:6L42MC

 Plate 90101-41B, 13

 1 Gasket Part No. 234

Plate 90201-85, лист 17 Part No.

 2 Piston ring right, 1st, 3rd Part No. 072

 Part No. 420*8*14.5

 Part No. 420*8*14.5

 3 Piston ring opposit, Part No. 084

 Part No. 420*8*14.5

 Part No. 420*8*14.5

 4 O-Ring, Part No. 143

 5 O-Ring Part No. 155

 Plate 90205-36В, 19

 6 O-Ring Part No. 145

 7 Screper ring, complete, Part No. 157

 8 Sealing ring, complete Part No. 170

 9 Sealing ring, complete Part No. 169

 10 Oil Scraper ring, complete Part No. 062

 11 Spring f. 157, 163, 170, Part No. 216

 12 Spring f. 062, Part No. 228

 13 Plate 90302-46, page 25 Part No.

 14 O-ring, Part No. 034

 15 O-ring, Part No. 046

 16 Connection for cylinder lubrication Part No. 022

 Plate 90612-09,

 17 Indicator cock Part No. 010

 18 Packing sleeve Part No. 014

 Plate 90704-23, page 86 Part No.

 19 O-ring Part No. 185

 Plate 90801-88,

 20 Gasket Part No. 037

 21 Piston Part No. 731

 22 O-ring Part No. 265

 23 O-ring Part No. 194

 24 Ring Part No. 312

 25 Safety valve Part No. 468

 26 Piston ring Part No. 419

 27 Overflow pipe Part No. 539

 28 Valve seat Part No. 588

 29 Valve spindle assy Part No. 611

 30 Sealing ring Part No. 755

 31 Sealing ring Part No. 706

 32 O-ring Part No. 660

 33 O-ring Part No. 684

 34 O-ring Part No. 743

 35 O-ring Part No. 767

 36 O-ring Part No. 780

 37 Air cylinder housing Part No. 108

 38 Oil cilinder housing Part No. 062

 Plate 90806-19В

 39 Sealing disk Part No. 022

 40 High-pressure pipe,complete Part No. 142

 Plate 90805-50В

 41 O-ring Part No. 279

 42 Ring Part No. 326

 Plate 90901-70B, page 109

 43 O-ring Part No. 091

 44 Spacer ring complete Part No. 149

 45 Spacer ring Part No. 150

 46 O-ring Part No. 162

 47 O-ring Part No. 233

 48 O-ring Part No. 270

 49 O-ring Part No. 316

 Plate 90910-37, page 113

 50 O-ring, Part No. 016

 51 O-ring, Part No. 053

 52 O-ring, Part No. 136

 53 Nozzle, Part No. 100

 54 Non-return valve Part No. 065

 Plate 90913-27, page 116

 55 High Pressure pipe, complete Part No. 107

 56 High Pressure pipe, complete Part No. 181

 57 High Pressure pipe, complete Part No. 193

 58 O-ring Part No. 215

 59 O-ring Part No. 227

 60 O-ringе Part No. 024

 Plate 91101-18, page 135

 61 Safety valve, complete Part No. 010

 62 Gasket Part No. 083

TYPE：BMZ B&W 6L42MC Mk3

 29 Safetu valve part No. 90801-67-468

 30 Lock washer 4-1702629 part No. 90603-39B-269
