NR15/R151

TYPE ：NR15/R151

 1TURBINE ROTOR Part No.: 520.001

 2 COMPRESSOR WHEEL Part No.: 520.005

 3 LABYRINTH RING Part No.: 520.006

 4 CARRIER Part No.: 520.009

 5 FEATHER KEY Part No.: 520.018

 6 MAGNETIC NUT Part No.: 520.124

 7 BEARING BUSH Part No.: 517.002

 8 O-RING SEAL Part No.: 517.063

 9 DISTANCE SLEEVE Part No.: 517.003

 10 SEALING RING Part No.: 517.015

 11 SEALING RING Part No.: 517.024

 12 SEALING RING Part No.: 517.034

 13 SEALING RING Part No.: 517.123

 14 INTERMEDIATE RING Part No.: 517.009

 15 TURBINE NOZZLE RING Part No.: 513.001

 TYPE ：TCA66-21107

 16 ORIFICE Part No.: 517.054

 17 O-RING SEAL Part No.: 517.063

 18 END COVER, TURBINE SIDE Part No.: 517.064

 19 LOCATING DISC Part No.: 517.066

 20 COUNTERSUNK SCREW Part No.: 517.067

 21 SEAL (TURBINE SIDE) Part No.: 517.070

 22 SEALING COVER, TURBINE SIDE Part No.: 517.072

 23 BEARING DISC Part No.: 517.075

 24 O-RING SEAL Part No.: 517.085

 25 LOCK WASHER PAIR Part No.: 517.095

 26 STUD Part No.: 517.100

 27 THRUST BEARING Part No.: 517.153

 28 COUNTER-THRUST BEARING Part No.: 517.154

 29 COVER Part No.: 517.159

 30 BEARING BUSH Part No.: 517.161

 31 BEARING BODY Part No.: 517.162

 32 SEALING COVER, COMPRESSOR SIDE Part No.: 517.197

 33 LABYRINTH RING (TURBINE SIDE) Part No.: 520.018

 34 RING NUT Part No.: 520.021

 35 THRUST RING Part No.: 520.028

 36 LABYRINTH RING (COMPRESSOR SIDE) Part No.: 520.035

 37 RING NUT Part No.: 520.038

 38 NOZZLE RING WITH COLLAR BOLTS Part No.: 513.001

 39 CIAMPING RING Part No.: 513.010

 40 HEXAGON BOLT Part No.: 513.013

 41 LOCKING WASHER Part No.: 513.015

 42 GUIDE BOLT Part No.: 513.021

 43 TAB WASHER Part No.: 513.024
