DAIHATSU DIESEL ENGINE 6DL16

TYPE: 6DL16

 1 Piston ring (1)-165A Part No.: E165100290A

 2 Piston ring (2)-165(B30) Part No.: E165100300B

 3 Piston ring (3)-165 Part No.: E165100310Z

 4 Piston ring (oil)-165 Part No.: E165100320A

 5 Cooling oil nozzle Part No.: E165300020B

 6 Cylinder head Part No.: E165600020Z

 7 Valve guide Part No.: E165600050Z

 8 Seat intake valve Part No.: E165600060A

 9 Seat exhaust valve Part No.: E165600120A

 10 Gasket cylinder head NO.23 Part No.: E165600230A

 11 Valve yoke quide Part No.: Р165610170 Z

 12 Valve stem seal Part No.: P145600250A

 13 Intake valve Part No.: E165700010Z

 14 Exhaust valve Part No.: E165800020Z

 15 Valve rotator Part No.: E165700080Z

 16 Gasket, head cover lower Part No.: E166300130Z

 17 Push rod Part No.: E166800020Z

 18 Tappet spring Part No.: E166800080Z

 19 O ring G35 Part No.: Z560203531ZZ

 20 Pin Part No.: C266203050Z

 21 Spring, nozzle Part No.: E166200540Z

 22 Nozzle,DL150T304.244(LOCK HOLE) Part No.: E166200320B

 23 Gasket bellows 80A Part No.: E162100180Z

 24 Exhaust bellows 80A Part No.: E162100170Z

 25 V band coupling 80A Part No.: E162100200Z

 26 O ring G55 Part No.: Z560205531ZZ

 27 Gasket ex. manifold Part No.: E162100140Z

 28 Packing, valve Part No.: C040070290B

 29 Spring Part No.: C040070370A

 30 VALVE,STARTING AIR Part No.: C040270430A

 31 Spring 1.0*10*23 Part No.: C040270502A

 32 L.O. pump drive shaft（2） Part No.: Е170500250Z

 33 L.O. pump gear（2） Part No.: Е170500260Z

 34 L.O. pump shaft Part No.: Е170500310Z

 35 bush（2） Part No.: Е170500320Z

 36 Bush（1） Part No.: M150500190Z

 37 Bush（2） Part No.: M150500200Z

 38 Inpeller 143R Part No.: C038602080Z

 39 Casing ring Part No.: C038602240Z

 40 Oring 148*3,5 Part No.: C038602250Z

 41 Mechanical seal (244) Part No.: C038602440Z

 42 Gasket, thermostat case Part No.: С037400250Z

 43 Thermostat assy. Part No.: M152700480Z

 44 Gauge DU1/4x60x4 Part No.: E173600012Z

 TYPE: RU 120A-1

 45 Turbine Shaft Part No.: 10-1

 46 Compressor Wheel Part No.: 20-1

 47 Turbine Shaft end Hexagon nut M10 Part No.: 10-4
