MAN B&W 5 L 21/31 Standard Tools for Normal Maintenance

PART DESCRIPTION

PART NO.

MAN B&W 5 L 21/31 Standard Tools for Normal Maintenance

52000-03

MAN B&W 5 L 21/31 Valve spring tightening device

52000-014

MAN B&W 5 L 21/31 Lifting tool for cylinder unit

52000-038

MAN B&W 5 L 21/31 Grinding tool for cylinder head/liner

52000-087

MAN B&W 5 L 21/31 Max. pressure indicator

52000-134

MAN B&W 5 L 21/31 Handle for indicator valve

52000-146

MAN B&W 5 L 21/31 Removing device for flame ring

52000-021

MAN B&W 5 L 21/31 Guide bush for piston

52000-045

MAN B&W 5 L 21/31 Fit and removaldevice for conn.rod bearing, incl.eye screws (2 pcs)

52000-069

MAN B&W 5 L 21/31 Lifting device for cylinder liner

52000-082

MAN B&W 5 L 21/31 Lifting device for piston and connecting rod

52000-104

MAN B&W 5 L 21/31 Testing mandrel for piston ring grooves,6.43 mm

52000-153

MAN B&W 5 L 21/31 Testing mandrel for piston ring grooves,8.43 mm

52000-165

MAN B&W 5 L 21/31 Piston ring opener

52000-190

MAN B&W 5 L 21/31 Supporting device for connecting rod and piston in the cylinder liner

52000-212

MAN B&W 5 L 21/31 Honing brush

52000-224

MAN B&W 5 L 21/31 Feeler gauge

52000-010

MAN B&W 5 L 21/31 Dismantling tool for main bearing upper shell

52000-035

MAN B&W 5 L 21/31 Tool for fixing of marine head for counterweight

52000-060

MAN B&W 5 L 21/31 Eye screw for lifting of charge air cooler

52000-036

MAN B&W 5 L 21/31 Cleaning tool for fuel injector

52000-013

MAN B&W 5 L 21/31 Pressure testing tool

52000-050

MAN B&W 5 L 21/31 Grinding device for nozzle seat, incl. plier for piston pin lock ring

52000-074

MAN B&W 5 L 21/31 Grinding device for nozzle seat, incl. plier for piston pin lock ring

52000-177

MAN B&W 5 L 21/31 Extractor device for injector valve

52000-407

MAN B&W 5 L 21/31 Eye screw for lifting of lubricating oil cooler

52000-032

MAN B&W 5 L 21/31 Fitting device for lub. oil cooler

52000-044

MAN B&W 5 L 21/31 Hydraulic tools box 1

52000-633

MAN B&W 5 L 21/31 Pressure pump,complete

52000-011

MAN B&W 5 L 21/31 manometer

52000-023

MAN B&W 5 L 21/31 Quick coupling

52000-405

MAN B&W 5 L 21/31 Rubber buffers

52000-507

MAN B&W 5 L 21/31 Hose with unions

52000-202

MAN B&W 5 L 21/31 Hose, 4000 mm

52000-537

MAN B&W 5 L 21/31 Quick coupling

52000-549

MAN B&W 5 L 21/31 Quick coupling

52000-836

MAN B&W 5 L 21/31 Nipple

52000-519

MAN B&W 5 L 21/31 Force-off device

52000-424

MAN B&W 5 L 21/31 Storage tank

52000-520

MAN B&W 5 L 21/31 Set of spare parts

52000-532

MAN B&W 5 L 21/31 Hydraulic tools box 2

52000-544

MAN B&W 5 L 21/31 Hydraulic tightening cylinder M33 x 2

52000-275

MAN B&W 5 L 21/31 Pressure part M33 x 2

52000-371

MAN B&W 5 L 21/31 Set of spare parts

52000-238

MAN B&W 5 L 21/31 Hydraulic tightening cylinder M30 x 2

52000-287

MAN B&W 5 L 21/31 Pressure part, short M22 x 2

52000-383

MAN B&W 5 L 21/31 Pressure part, long M22 x 2

52000-096

MAN B&W 5 L 21/31 Tension screw M22 x 2

52000-131

MAN B&W 5 L 21/31 Set of spare parts

52000-251

MAN B&W 5 L 21/31 Turn pin

52000-556

MAN B&W 5 L 21/31 Turn pin

52000-568

MAN B&W 5 L 21/31 Turn pin

52000-334

MAN B&W 5 L 21/31 Angle piece

52000-358

MAN B&W 5 L 21/31 Measuring device

52000-448

MAN B&W 5 L 21/31 Hydraulic tools box 3

52000-581

MAN B&W 5 L 21/31 Hydraulic tightening cylinder M30 x 2

52000-263

MAN B&W 5 L 21/31 Pressure part, short M30 x 2

52000-072

MAN B&W 5 L 21/31 Pressure part, long M30 x 2

52000-059

MAN B&W 5 L 21/31 tension screw

52000-118

MAN B&W 5 L 21/31 Set of spare parts

52000-226

MAN B&W 5 L 21/31 Turn pin

52000-593

MAN B&W 5 L 21/31 Turn pin

52000-603

MAN B&W 5 L 21/31 Turn pin

52000-334

MAN B&W 5 L 21/31 Container complete for water washing of compressor side

51205-318

MAN B&W 5 L 21/31 Blowgun for dry cleaning of turbocharger

51210-136

MAN B&W 5 L 21/31 Resetting device for hydraulic cylinder

52000-436

MAN B&W 5 L 21/31 Broad chissel

52000-473

MAN B&W 5 L 21/31 Broad chissel

52000-485
