MAIN AIR COMPRESSOR V-LINE WATERCOOLED V 375,msckobe:3865

MAKER:HAMWORTHY KSE LIMITED

BX 80 FLE 10'==>DRIVE COUPLING ELEMENT/3010/080/055-756094 DWG NO 641600 (PCS)

15 FIG 5.4 ==>CONNECTING ROD FIRST STAGE (PCS)

16 FIG 5.4==>BEARING-BIG END CYLINDRICAL ROLLER (PCS)

18 FIG 5.3==>SPACER CONNECTING ROAD/CRANKSHAFT (PCS)

19 FIG 5.5 ==>CONNECTING ROD SECOND STAGE (PCS)

20 FIG 5.5==>BEARING-BIG END CYLINDRICAL ROLLER (PCS)

35 FIG 5.4 ==>PISTON FIRST STAGE (PCS)

37 FIG 5.4==>PISTON RING TAPER FACED (1st STAGE) (PCS)

38 FIG 5.4==>PISTON RING BARREL FACED (1st STAGE) (PCS)

39 FIG 5.4 ==>LINER FIRST STAGE (PCS)

40==>GUDEON PIN(FIRST STAGE)MAINTENANCE MANUAL M-68/DRAWING SECTION 5/PAGE 5-5 (PCS)

50 FIG 5.4 ==>CONCENTRIC VALVE FIRST STAGE (PCS)

61 FIG 5.5==>PISTON RING S.O.C. (PCS)

62 FIG 5.5==>PISTON RING TAPPER FACED (2nd STAGE (PCS)

63 FIG 5.5==>PISTON RING BARREL FACED (2nd STAGE (PCS)

75 FIG.5.5 ==>CONCENTRIC VALVE SECOND STAGE (PCS)

167 FIG.5.4 ==>FILTER ELEMENT (PCS)
