122924O-LUCK PURIFIER

 FOR:SPARES F.O. No1, 2 & L.O. PURIFIERs

Maker : MITSUBISHI KAKOKI KAISHA. LTD Type : SELFJECTOR

Serial No : 3301914; 3301915; 3301916 Drawing No. : BOOK M3-04,

BOWL  ASSEMBLYMITSUBISHI KAKOKI.SJ30F.102

MITSUBISHI KAKOKI.SJ30F.107

MITSUBISHI KAKOKI.SJ30F.114

MITSUBISHI KAKOKI.SJ30F.116

MITSUBISHI KAKOKI.SJ30F.117

MAIN SEAL RING

MITSUBISHI KAKOKI.SJ30F.118

BOWL BUSH

MITSUBISHI KAKOKI.SJ30F.123

VALVE GUIDE

MITSUBISHI KAKOKI.SJ30F.125

MITSUBISHI KAKOKI.SJ30F.126

MITSUBISHI KAKOKI.SJ30F.127

PILOT VALVE

MITSUBISHI KAKOKI.SJ30F.128

VALVE SEAT

MITSUBISHI KAKOKI.SJ30F.130

MITSUBISHI KAKOKI.SJ30F.130

“O”-RING

MITSUBISHI KAKOKI.SJ30F.131

VALVE NUT

MITSUBISHI KAKOKI.SJ30F.132

THERMOMETER

MITSUBISHI KAKOKI.SJ30F.316

VERTICAL SHAFT 60 HZ

MITSUBISHI KAKOKI.SJ30F.501

LOCK NUT

MITSUBISHI KAKOKI.SJ30F.503

MITSUBISHI KAKOKI.SJ30F.505

UPPER SPRING

MITSUBISHI KAKOKI.SJ30F.508

BALL BEARING (1)

MITSUBISHI KAKOKI.SJ30F.511

MITSUBISHI KAKOKI.SJ30F.517

BEARING CAP (2)

MITSUBISHI KAKOKI.SJ30F.518

FLAT SPRING

MITSUBISHI KAKOKI.SJ30F.520

BEARING (2)  2305

MITSUBISHI KAKOKI.SJ30F.529

BALL BEARING (3)

MITSUBISHI KAKOKI.SJ30F.532

SPACER  (2)

MITSUBISHI KAKOKI.SJ30F.534

SPRING SEAT

MITSUBISHI KAKOKI.SJ30F.535

STEEL BALL

MITSUBISHI KAKOKI.SJ30F.536

BEARING COVER  (2)

MITSUBISHI KAKOKI.SJ30F.537

COLLAR

MITSUBISHI KAKOKI.SJ30F.538

OPERATING WATER DISC

MITSUBISHI KAKOKI.SJ30F.701

OPERATING WATER NOZZLE

MITSUBISHI KAKOKI.SJ30F.703

OPERATING WATER CHAMBER

MITSUBISHI KAKOKI.SJ30F.705

TONGUED WASHER

MITSUBISHI KAKOKI.SJ30F.707

“O”-RING

MITSUBISHI KAKOKI.SJ30F.708

CHAMBER COVER

MITSUBISHI KAKOKI.SJ30F.709

PACKING

MITSUBISHI KAKOKI.SJ30F.711

BALL BEARING  6307

MITSUBISHI KAKOKI.SJ30F.602

SPIRAL GEAR  60 HZ

MITSUBISHI KAKOKI.SJ30F.616

COLLAR

MITSUBISHI KAKOKI.SJ30F.617

FRICTION PULLEY

MITSUBISHI KAKOKI.SJ30F.618

FRICTION BLOCK   60 HZ

MITSUBISHI KAKOKI.SJ30F.621

OIL SEAL

MITSUBISHI KAKOKI.SJ30F.625

COLLAR

MITSUBISHI KAKOKI.SJ30F.627

SOCKET SET SCREW

MITSUBISHI KAKOKI.SJ30F.628

OIL SEAL

MITSUBISHI KAKOKI.SJ30F.G03

DRIVE GEAR

MITSUBISHI KAKOKI.SJ30F.G09

DRIVEN GEAR

MITSUBISHI KAKOKI.SJ30F.G10

BUSH

MITSUBISHI KAKOKI.SJ30F.G11

SAFETY JOINT

MITSUBISHI KAKOKI.SJ30F.G22

MITSUBISHI KAKOKI.SJ30F.NA
