011187L-ORIENTAL

"Spare Part For: Hose Handling Crane Deck

Manufacturer: ORIENTAL Precision & Engineering Co.LTD

Type: HHI 700-1527 ( 15T x 27M )

Searial.No.: 31409

Hoisting capacity: SWL 15.0 ton Over load test: Rated load (S.W.L)x1.25

Hoisting lift: Max. 36.0m

Hoistins speed: abt. 10m/min. at rated load ( by 2layer)

abt. 20m/min. at no load ( by 2layer)

Working radius : Max. 27.0m - Min 5.9m

Jib luffing time : abt. 165 secv(Luffing up)

 abt. 140 secv(Luffing down)

Slewing speed : abt 0.4rpm

Wire rope: Dia.18 mm npn-rotation type with galvanized

Safety factor : in pursuance of rule requirement" TIME RELAY  MA4N-A  (0-12SEC). RANGE:0.12sec-300h.                                                      POWER: 24-240V, 50-60Hz. 5.3VA                  CONTACT:3A 250V a.c. ORIENTAL PRECISION & ENGINEERING.
