010553A-YOG-013

 "AUX. ENGINE TURBO

CHARGER CARTRIDGE ***

FOR CRITICAL SPARE

FIG.1AND2

MITSUBISHI EXHAUST -

GAS TURBO CHARGER

TYPE-MET30SR

SPEC.-

FS3H37DW312HC100M

MAX.CONT. SPEED-29400

MAX.CONT.GAS TEMP.-

580 C

MITSUBISHI HEAVY

INDUSTRIES. LTD.TOKYO

JAPAN

" MITSUBISHI HEAVY INDUSTRIES.MET30SR.60

 "AUX.ENGINE

TURBOCHARGER

NOZZLE *** DRAWING -

FIG. 1AND 2

MITSUBISHI EXHAUST -

GAS TURBO CHARGER

TYPE-MET30SR

SPEC.-

FS3H37DW312HC100M

MAX.CONT. SPEED-29400

MAX.CONT.GAS TEMP.-

580 C

MITSUBISHI HEAVY

INDUSTRIES. LTD.T" MITSUBISHI HEAVY INDUSTRIES.MET30SR.22

 EXHAUST PIPE  MITSUI ENGINEERING&SHIPBUILDING.10K98MC‐C (MKVI).522A 2

 SCREW MITSUI ENGINEERING&SHIPBUILDING.10K98MC‐C (MKVI).522A 29

 EXPANSION JOINT MITSUI ENGINEERING&SHIPBUILDING.10K98MC‐C (MKVI).522A 1
