0217115W-CPU

"FOR ANCHOR WINDLASS AND MOORING WINCH - PORT

BRAND TEN HORN (SEC / THR MARINE)

TYPE EAMW 46U3-100KN

BUILDING YEAR 2011

SERIAL NO. 60060372

LOCATION:DECK

OPERATING SYSTEM:DECK MACHINERY

WINCH DRIVE:ELECTRIC" "CENTRAL UNIT CPU 224 24VDC.14 INTEGR DE 24V. 10 INTEGR. DA 24V

PLC SYSTEM SURVEY

=======================

ELECTRIC ANCHOR MOORING WINCH

SERIAL NUMBER 1079341

CAD - DOCU. NO 1079341/1.01

VOLTAGE: 380 / 50HZ

CONTR. VOLTAGE: 230V 50HZ / 24V DC

POWER : 11 / 22 / 22 KW

NOMINAL CURRENT: 29 / 43 / 42 A

STARTING CURRENT: 95 / - / - A

PART LIST:

INDICATION ON DRAWING =W - 7A1

=W1 / 7.3

SPECIFICATION CENTRAL UNIT CPU 224 24VDC 14 INTEGR DE 24V. 10 INTEGR. OA 24V

ARTICLE NUMBER / TYPE NUMBER 4520 6ES7214 - 1AD22 - OXBO

6ES7214 - 1AD22 - OXBO

PRODUCER: SIEMENS

============

ITEM NO.: 4520 6ES7214 - 1AD22 - OXBO

FOR SWITCH CABINET ANCHOR/MOORING WINCH W1

DWG. NO.: =W 1/7 PLC SYSTEM SURVEY" TEN HORN .EAMW46U3-100KN .CPU 224 24VDC
