"UNION STAINLESS STEEL 10MM, FLARELESS

These stainless steel flareless tube fittings have the following characteristics

and specifications. 1. Applicable for extreme high and low temperatures 2.

Applicable for high pressure 3. May be used for vacuum lines 4. May be

used for gas analyzer lines when high accuracy is required." NA..NA.734403

"NUT STAINLESS STEEL FOR TUBE, FITTING 10MM

These stainless steel flareless tube fittings have the following characteristics

and specifications. 1. Applicable for extreme high and low temperatures 2.

Applicable for high pressure 3. May be used for vacuum lines 4. May be

used for gas analyzer lines when high accuracy is required. Following items

are for use with the tube fittings." NA..NA.734433

HEX HEAD BOLT/NUT STEEL UNGALV, M24 X 80MM NA..NA.691396

HEX HEAD BOLT/NUT STEEL UNGALV, M20 X 70MM NA..NA.691329

HEX HEAD BOLT/NUT STEEL UNGALV, M6 X 30MM NA..NA.691111

STUD WHOLE THREADED STEEL, M20 X PITCH2.5 1000MM NA..NA.692031

STUD WHOLE THREADED BRASS, M16 X PITCH2.0 1000MM NA..NA.692079

HEX HEAD BOLT/NUT STAINLESS, STEEL M8 X 40MM NA..NA.692543

HEX HEAD BOLT/NUT STAINLESS, STEEL M6 X 40MM NA..NA.692513

"SCREW SOCKET FLAT HEAD, WITH FURTHER DETAIL

Nom size M3 : Pitch=0.5 d1=3 D=6 H=1.7 B=2 C=2.3 L=6-20 s=12, Nom size

M4 : Pitch=0.7 d1=4 D=8 H=2.3 B=2.5 C=2.9 L=6-50 s=14, Nom size M5 :

Pitch=0.8 d1=5 D=10 H=2.8 B=3 C=3.6 L=8-50 s=16, Nom size M6 : Pitch=1

d1=6 D=12 H=3.3 B=4 C=4.7 L=8-50 s=18, Nom size M8 : Pitch=1.25 d1=8

D=16 H=4.4 B=5 C=5.9 L=12-70 s=22, Nom size M10 : Pitch=1.5 d1=10

D=20 H=5.5 B=6 C=7.0 L=15-70 s=26, Nom size M12 : Pitch=1.75 d1=12

D=24 H=6.5 B=8 C=9.4 L=20-50 s=30, Nom size M16 : Pitch=2 d1=16 D=30

H=7.5 B=10 C=11.7 L=25-60 s=38 How to order : CODE 690601, Name Flat

head socket screw, Material, Nominal size & thread, Length" NA..NA.690601
