121516H-BUTTERFLY VALVE

Subject: BUTTERFLY VALVE FOR FIRE SYSTEM "BUTTERFLY VALVE WITH ACTUATOR DN50；DWG:53-03-100,DN50,Subject: BUTTERFLY VALVE FOR FIRE SYSTEM

Material body - Ductile Iron

disc - Aluminium Bronze

shaft - Stainless Steel SS316

seals - EPDM High Temp

Actuator - Aluminium Alloy , Steel

Surface Treatment - Polyurethane Coating

Power Supply - 110/ 220/ 380V AC

Degree of Protection - Actuator: IP67

Space Heater - 6W

Nominal pressure - PN16

Nominal diameter - DN50 2""

A - 162 mm

B - 244 mm

C - 42 mm

D - 18 mm

E - 160 mm

F - 132.5 mm

G - 113 mm

H - 18 mm

N-diam. - 4x18mm

diam D1 - 125 mm

diam. D2 - 52.8 mm

Actuator Type - DCL-05

Power Consu. - 10 W

Current max. - 0.16 A

Weight - 4.5 kg

Prod № - 777445

" "WILHELMSEN.NA..PN16,DCL-05B,

220V,60HZ,50NM"
