030746L-200HW

"MAKER: MARITIME PUSNES AS

TYPE: 200 HW

" "COUNTERSUNK SCREW W/ GROOVE

PARTS LIST FOR : BAND BRAKE, HYDRAULIC DIA=1800 MM X 8 IN. , CABLE LIFTER UNIT (W1, W2)

TYPE: K-CU

POS. NO.: 134

IMPA CODE : 69 42 01(

MATERIAL : BRASS COUNTER SUNK SCREW WITH HEXAGONAL NUTS( SS)

LENGTH = 40.0 MM

M 10 X 1.5" MARITIME PUSNES AS.200 HW.406770.008

"MAKER: MARITIME PUSNES AS

TYPE: 200 HW

" "BRAKE LINING

PARTS LIST FOR : BAND BRAKE, HYDRAULIC DIA=1800 MM X 8 IN. , CABLE LIFTER UNIT (W1, W2)

TYPE: K-CU

POS. NO.: 201

IMPA NO : 81 16 76

DIMENSION: L= 11300 MM, , THICKNESS: 16.0 MM,WIDTH = 200 MM ( FOR TWO WINDLASS BRAKE LINING)" MARITIME PUSNES AS.200 HW.001631.013

"MAKER: MARITIME PUSNES AS

TYPE: 200 HW

" "BRAKE LINING

PARTS LIST FOR : BAND BRAKE, DIA=1200MM /3IN., FLANGE DIA=1500 MM, ST. LESS, BRAKE RIM (W1, W2, M1, M2, M3, M4, M5, M6)

TYPE: 200 HW

POS. NO.: 201

IMPA NO : 81 16 76

DIMENSION: L= 60200 MM, , THICKNESS: 12.0 MM,WIDTH = 75.0 MM ( FOR SIX WINCHES AND TWO WINDLASS BRAKE LINING)" MARITIME PUSNES AS.200 HW.001631.051
