101883O-ANOOR ANCHOR

"FOR:                                     Machinery Name: ANCHOR CHAIN CABLE

DRAWING NO: NC1Z-080-2A

MFG NO: NC1-080

MAKER.: NEW JAPAN MECHANICAL CHAIN MFG. CO. LTD.

                   HEAD OFFICE: 16-4, ISOURA-CHO

                   NIIHAMA-CITY EHIME JAPAN

                   TEL: (0897)-32-6509, FAX:  (0897)-32-6496" "ANCHOR CHAIN CABLE SET

TOTAL LENGTH: 316.25 M

NOMINAL DIA: 73 MM FLASH-BUTT WELDED STUD LINK

ANCHOR CHAIN CABLE GRADE 3

A DIA 73 MM ×27.5 M (APPROX) ×20 LENGHTS

B DIA 73 MM ×27.5 M (APPROX) ×2 LENGHTS

C DIA 73 MM ×13.75 M (APPROX) WITH SWIVEL  ×2 LENGHTS

CERTIFICATION: NIOPPON KAIJI KYOKAI (NK)

PROOF TEST LOAD: 2790 KN

BREAKING TEST LOAD: 3990 KN" NEW JAPAN MECHANICAL.NA.NC1Z-080-2A

"FOR:                                     Machinery Name: ANCHOR CHAIN CABLE

DRAWING NO: NC1Z-080-2A

MFG NO: NC1-080

MAKER.: NEW JAPAN MECHANICAL CHAIN MFG. CO. LTD.

                   HEAD OFFICE: 16-4, ISOURA-CHO

                   NIIHAMA-CITY EHIME JAPAN

                   TEL: (0897)-32-6509, FAX:  (0897)-32-6496" "ANCHOR

PARTICULAR WEIGHT: 6525 KGS

SHIP NO: S-1345

IMABARI SHIP BUILDING CO, LTD." NEW JAPAN MECHANICAL.NA.F-0103
