SPARE PARTS ASSEMBLY

INPUT ASSEMBLY

 1 O-RING Part No.: “GB/T 3452.1-1992

 184.2*5.7”

 2 SUPPORTING RING Part No.: 200 GB894-86

 3 BEARING Part No.: NU240E MA6C3

 4 SUPPORTING RING Part No.: GWC52 59-01-258

 5 SPACER RING Part No.: GWC52 59-01-261

 6 ADJUSTING RING Part No.: GWC52-01-262

 7 BEARING Part No.: 22336 CCW33 C3

 8 DISC Part No.: GWC52 59-01-264

 9 BOLT Part No.: “GB70 1-2000

 M20*45”

 10 INPUT GEAR(I=4:1) Part No.: GWC52 59=01-287/35

 CLUTCH ASSEMBLY

 11 BEARING Part No.: 22336cc/w33

 12 SPACER Part No.: GWC52 59-02-173

 13 CLUTCH Part No.: “3/0574/5014/0

 52.59-183”

 14 X-RING UNIT Part No.: “X” 370

 15 Part No.: “X” 180

 16 SPRING Part No.: “4/0991/0209/0

 52.59-189”

 17 EXFRICTIONAL PLATE Part No.: “3/0530/0048/0

 52.59-181”

 18 INFRICTION PLATE Part No.: “3/0539/00600/2

 52.59-180”

 19 NUT Part No.: GWC52 59-02-177

 20 BEARING Part No.: 3G32632EH

 21 SPACER Part No.: GWC52 62-02-214

 22 BEARING Part No.: 176332Y

 23 SCREW Part No.: “GB/T70 1-2000

 M12*30”

 24 PIN Part No.: “GB119-2000

 B16*45”

 25 GUIDING RING SLEEVE Part No.: GWS52 62-03-191

 26 SPACER Part No.: GWC52 59-02-207

 27 TAB WASHER FOR ROUND NUT Part No.: GB858-88 160

 28 DRAIN VALUE PISTION Part No.: “4/0903/0079/0

 52.59-199”

 29 SCREW Part No.: “GB/T5783-2000

 M6*40”

 30 SCREW Part No.: GB/T71-2000

 31 PRESSURED SPRING Part No.: “GB2089-94

 0.5*4*31”

 32 SPACER Part No.: GWC52 59-02-213

 33 BEARING Part No.: 3G32248EH

 34 PISTON RING Part No.: 300-01-016

 OUT PUT ASSEMBLY

 35 OUTPUT SHAFT Part No.: GWC52.59-04-240A

 36 SCREW Part No.: “GB70 1-2000

 M24*60”

 37 COVER Part No.: GWC52 59-04-221

 38 BEARING Part No.: “GB5859-84

 29436”

 39 SPACER Part No.: GWC52 59-04-230

 40 SPACER Part No.: GWC52 59-04-233

 41 BEARING Part No.: “GB283-87

 32340”

 42 SPACER Part No.: GWC59 04-232

 43 SPACER Part No.: GWC59 59-04-234

 44 BEARING Part No.: “GB283-87

 3032160”

 45 O RING Part No.: “GB/T3452 1-1992

 290*7”

 46 SPACER Part No.: GWC52 59-04-001

 47 SPRING Part No.: “GB2089-80

 3.5*18*70”

 HOUSING ASSEMBLY

 48 PIN Part No.: “GB/T117-2000

 ”

 49 PACKING (IN METER) Part No.: NO:137

 50 SEAL Part No.: “Q20-03

 60”

 51 PACKING (IN METER) Part No.: NO:137

 52 INSPECTIVE COVER GASKET Part No.: 3/0985/0032/0

 53 INSPECTIVE COVER GASKET Part No.: 3/0985/0031/0

 PUMP TRANS ASSEMBLY

 54 PIN Part No.: “GB/T117-2000

 10*30”

 55 SEAL Part No.: “Q20-03

 33”

 56 SEAL Part No.: GWC52 59-06-121

 57 BEARING Part No.: 212H

 58 NILOS RING Part No.: 4/0985/0687/0

 59 REPAIR KIT FOR 4-WAY VALVE Part No.: GWC-157

 60 GEARBOX OIL FILTER Part No.: Γ41-43
