DAIHATSU DIESEL ENGINE PARTS 8DKM-28

DAIHATSU 8DKM-28 SN:D280806029

 CHAPTER 3/ ITEM 11: PISTON & CONNECTING ROD

 1 PISTON A-3 Part No.: E 285170030

 CHAPTER 3/ ITEM 13: CYLINDER HEAD

 2 SEAT EXHAUST VALVE-10 Part No.: E 285670100

 3 O RING 509 Part No.: Z560102024DZ

 CHAPTER 3/ ITEM 14: INTAKE VALVE

 4 INTAKE VALVE- 2 Part No.: E 285770020

 CHAPTER 3/ ITEM 15: EXHAUST VALVE

 5 EXHAUST VALVE- 3 Part No.: E 285870030

 6 VALVE ROTATOR Part No.: E 285770060

 CHAPTER 3/ ITEM 16: ROCKER ARM

 7 SCREW ROCKER ARM- 12 Part No.: E 285970120

 CHAPTER 3/ ITEM 17:STARTING AIR VALVE

 8 GASKET STARTING VALVE Part No.: E 286070090

 9 STARTING VALVE ASSY. Part No.: ASSY. / 901

 CHAPTER 3/ ITEM 18.1:FUEL OIL INJECTION DEVICE

 10 CLAMP, ZOZZLE HOLDER Part No.: E 286270060

 CHAPTER 3/ ITEM 18.2:FUEL OIL INJECTION DEVICE(FUEL OIL NOZZLE HOLDER)

 11 NOZZLE DLF 140U5210- 33 Part No.: E 286270330

 12 NOZZLE HOLDER- 14 Part No.: E 286270140

 13 INLET CONNECTOR Part No.: E 286273200

 14 PIN- 302 Part No.: E 286273020

 15 PIN- 304 Part No.: E 326203040

 16 CAP NUT Part No.: E 326273120

 17 RETAINER NUT Part No.: E 326273190

 18 SPRING SEAT Part No.: E 326203050

 19 SPACER Part No.: E 326253100

 CHAPTER 3/ ITEM 19:INDICATOR&SAFETY VALVE

 20 INDICATOR & SAFETY VALVE Part No.: E 206959610

 CHAPTER 3/ ITEM 23:FUEL OIL INJECTION PUMP

 21 PLUNGER ASSY.- 209 Part No.: E 286472090

 22 DELIVERY VALVE – 215 Part No.: E 286472150

 23 GUIDER PLUNGER- 230 Part No.: E 326472300

 24 CONTROL SLEEVE- 235 Part No.: E236472350

 25 BOLT – 220 Part No.: E286472200

 26 F.O INJECTION PUMP ASSY Part No.: E 286470030

 27 GASKET- 246 Part No.: E326472460

 28 GASKET- 256 Part No.: E326472560ZZ

 29 GASKET- 251 Part No.: E326472510ZZ

 CHAPTER 3/ ITEM 27.3:EXHAUST MANIFOLD

 30 BELLOW A – 15 (6 holes type) Part No.: E 282175150

 CHAPTER 4/ ITEM 3.1:LUBRICATING OIL PUMP

 31 OIL SEAL – A526 Part No.: Z461507212SB

 CHAPTER 4/ ITEM 6.1: GAUGE BOARD

 32 PRESS . GAUGE -B3 Part No.: Y703094000AZ

 33 PRESS . GAUGE -B4 Part No.: Y703096024AZ

 34 PRESS . GAUGE -B5 Part No.: Y703001041AZ

 35 PRESS . GAUGE -B6 Part No.: Y703001050AZ

 36 PRESS . GAUGE -B7 Part No.: Y703094002AZ

 37 FLEX. CABLE- C6 Part No.: C061501934

 THERMOMETER

 38 B2-THERMOMETER 600OC Part No.: Y255004160ZZ

 II GENERATOR ENGINE – TYPE : KTA 19-G2M (336kw-1500rpm). Serial No. 41077919,41077920, 41077921. Maker : Chongqing Cummins China

 CYLINDER BLOCK

 39 SEAL D-RING Part No.: 3014668/38

 40 SEAL D-RING Part No.: 3011076/39

 41 SEAL OIL Part No.: 3081489/40

 CRANKSHAFT AND MAIN BEARING

 42 SHELL,MAIN BEARING Part No.: AR12270

 ROCKER LEVER

 43 SCREW, HEXAGON HEAD CAP Part No.: 108602/07-13

 44 SCREW, SLOTTED SET Part No.: 168306/07-16

 CAMSHAFT FOLLOWER

 45 ROD PUSH Part No.: 3057139

 46 ROD PUSH Part No.: 3017961/20

 ALTERNATER MOUNTING

 47 BELT , VRIBBED Part No.: 206996/1

 COVER, GEAR HOUSING

 48 SEAL OIL Part No.: 3016792

 49 SEAL,OIL Part No.: 3016794

 50 SEAL OIL Part No.: 3628895/26

 51 SEAL O-RING Part No.: 3201125/27

 52 BUSHING Part No.: 132770/21

 53 BUSHING Part No.: 205133/22

 FLYWHEEL HOUSING

 54 SEAL O-RING Part No.: 205247/2

 55 SEAL,OIL RR CRK Part No.: 3870890

 56 SEAL RECTANGULAR RING Part No.: 3096260/14

 HEAT EXCHANGER

 57 PLUG,ZINC ELECTRODE Part No.: 68241/31

 58 COVER HEAT EXCHANGER Part No.: 3011324/33

 59 GASKET HEAT EXCHANGER Part No.: 3011325/34

 60 COVER HEAT EXCHANGER Part No.: 3011329/35

 61 GASKET HEAT EXCHANGER Part No.: 3011332/36

 62 SEAL O-RING Part No.: 3011337/37

 AIR INTAKE

 63 SEAL WATER CONNECTION Part No.: 206808/3

 OIL PAN

 64 GASKET OIL PAN Part No.: 3073213/19

 MTG,OIL PAN

 65 GASKET OIL PAN Part No.: 3042590/2

 PISTON AND CONNECTION ROD

 66 BEARING CONNECTING ROD Part No.: 205840/6

 67 RING COMPRESSION PISTON Part No.: 3070589/10

 RING COMPRESSION PISTON Part No.: 3090460/11

 RING OIL PISTON Part No.: 3090450/12

 CYLINDER HEAD

 68 COLOLET VALVE Part No.: 205091/1

 69 RETAINER VALVE SPRING Part No.: 205094/2

 70 VALVE INTAKE Part No.: 207241/3

 71 VALVE EXHAUST Part No.: 3035110/4

 72 GUIDE VALVE SPRING Part No.: 3001663/6

 73 INSERT,VAVEL Part No.: 205093/8

 74 INSERT,VAVEL Part No.: 3026296

 MTG.CYLINDER HEAD

 75 GASKET CYLINDER HEAD Part No.: 3634664

 INJECTOR

 76 INJECTOR Part No.: 3016676

 77 RING,INJECTOR SE Part No.: 207244/17

 78 SEAL ORING Part No.: 193796/8

 79 LINK,INJECTOR PL Part No.: 205462/18

 80 BARREL&PLUNGER Part No.: FP3037292

 81 SCREEN FILTER Part No.: FP 3008706

 EXHAUST MANIFOLD

 77 GASKET EXHAUST Part No.: 3043097/4

 WATER PUMP

 78 SEAL O-RING Part No.: 146523/1

 79 BEARING BALL Part No.: S16062/20

 80 BEARING BALL Part No.: S16069/21

 81 SEAL OIL Part No.: 206948/24

 82 SHAFT WATER PUMP Part No.: 3042827/27

 83 SEAL WATER PUMP Part No.: 3609826/26

 84 SHAFT WATER PUMP Part No.: 3202007/37

 85 GASKET WATER PUMP Part No.: 3202283/38

 86 BEARING THRUST Part No.: 3026556/45

 87 RETAINER SHAFT Part No.: 3034721/46

 88 IMPELLER WATER PUMP Part No.: 205243/28

 89 BUSHING Part No.: 205156/43

 ROCKER LEVER

 90 SCREW SLOTTED SET Part No.: 168306/16

 91 NUT BEGULAR HEXAGON Part No.: S212/15

 92 LEVER LOCKER Part No.: 3053478

 93 LEVER LOCKER Part No.: 3053476

 94 LEVER LOCKER Part No.: 3053477

 95 GASKET SET FOR LOWER ENGINE Part No.: FP 4295803

 96 GASKET SET FOR UPPER Part No.: FP 4295804

 TURBOCHARGER

 97 TURBOCHARGER REPAIR KIT Part No.: 3545647

 98 FUEL FILTER Part No.: 3315843/2

 99 ELMENT LUB OIL FILTER Part No.: 3889310

 100 BYPASS OIL FILTER Part No.: 3889311

 101 DO FILTER Part No.: P552020

 102 FUEL PUMP(T.L.N) Part No.: 3899014

 103 OIL PUMP Part No.: 3047549

 BREATHER LOCATION

 104 HOSE,PLAIN Part No.: 64775

 105 CLAM,HOSE Part No.: 43828

 FUEL TUBING

 106 CONECTION, FUEL BLOCK Part No.: 207442

 107 SEAL,FRRULE Part No.: 3633046

 108 CONECTION,TUBE Part No.: 3031404

 OTHERS

 109 LOW OIL PRESSURE SWITCH Part No.: 3056344

 110 COOLANT TEMP SWITCH Part No.: 3056353

 111 TRANSDUCER Part No.: 3015237

 112 MAGNETIC SWITCH Part No.: 3050692

 113 MAGNETIC PICKUP Part No.: 3034572
